双断开机械功用
|
INO+INC Force Break snap action强迫断开快速机芯
|
额定电压/电流
|
10(4)A, 125, 250VAC / 6(2)A, 380VAC For inductance Load, Cosφ=0.4
|
接触电阻
|
25mΩ max. (initial value)
|
绝缘电阻
|
100mΩ min. (at 500VDC)
|
电介强度
|
1000VAC, 50/60 Hz for 1 minute between terminals of the same polarity
|
1500VAC, 50/60 Hz for 1 minute between current-carrying and non-current-carrying metal parts
|
1500VAC, 50/60 Hz for 1 minute between each terminal and ground
|
电气寿命
|
500,000 at 10A 250VAC Resistive
|
机械寿命
|
10, 000, 000 operations min. (under rated conditions)
|
操作速度
|
5mm/s to 0.5m/s
|
防水防尘能力
|
IP66(防压力水柱级)
|
上升温度
|
Max 30℃ over ambient temperature at rated voltage/current
|
合乎标准
|
Cenelec EN 50041, EN 50047, IEC 337-1, VDE 0660
|
操作温度
|
-5℃~+65℃ (with no icing)
|
保存温度
|
-5℃~+65℃ (with no icing)
|
湿度
|
95% RH Max.
|
冲击系数
|
Mechanical durable: 1000m/s2 min.
|
Malfunction: 300m/s2 min.
|
振动频率
|
Malfunction: 10 to 55Hz, 1.5mm double amplitude
|
端子螺丝扭力
|
6-8 kgf-cm
|
其他螺丝扭力
|
Cover 12-14 kgf-cm/Head 8-9 kgf-cm/Mounting 50-60 kgf/cm
|
裸铜线尺寸
|
φ2 Max
|
电缆尺寸
|
φ12 Max(IP 65 if use cable φ8-9)
|
